Alloy frame
Tapered
Headtube E2
Custom
butted tubing / internal cable routing
Bosch Gen3
/ Integr. removable Battery / Boost 148x12mm
DO
Kickstand mount / Range Booster Ready
Travel
120mm
Fork
SR Suntour
XCM34 Coil
15x110mm QR
axle / Tapered Steerer
Remote
Lockout / 120mm travel
Remote
System
SR Suntour
Remote
Drive Unit
Bosch
Active Line Plus
EU: 25kmh /
INT: 20mph
Battery
PowerTube
500Wh
Display
Bosch
Purion
Charger
2A Charger
Rear
Derailleur
Shimano
RD-M3100 / 9 Speed
Shifters
Shimano
SL-M2000
Crankset
FSA CK-200
/ 165mm
Chainring
FSA WB437
32T w/CG
Chain
KMC e9S
Cassette
Shimano
CS-HG200-9 ACERA 11-36
Brakes
Shimano
BR-MT200 Disc
Rotor
Front:
SM-RT30 CL 180mm / Rear: RT-EM300 CL 180mm
Handlebar
Syncros 3.0
720mm / 31.8mm / 9° / 12mm rise
Syncros
Comfort lock-on grips
H'stem
Syncros 3.0
/ 7° / Black
Seatpost
Syncros 3.0
/ 31.6mm
Seat
Syncros
ER2.5
Headset
Syncros OE
/ Tapered 1.5"-1 1/8"
semi integ.
OD 50/62mm / ID 44/56mm
Hub (Front)
Shimano
HB-MT400-B CL / 15x110mm
Hub (Rear)
Shimano
FH-MT400-B CL / Boost 12x148mm
Spokes
Stainless
Black
Rims
Syncros X18
/ 32H / 30mm / Pin Joint
Front Tire
Kenda
Booster 29x2.6" / 30TPI
Rear Tire
Kenda
Booster 29x2.6" / 30TPI
Lights
Bosch Light
Cable pre-installed F&R
Approx
weight in KG
24.3
Approx
weight in LBS
53.57
Max. System
Weight
128kg
The overall
weight includes the bike, the rider, the equipment, and possible additional
luggage.
